Woven Geotextile Stabilization Fabric

Woven Geotextile stabilization fabric

315 Woven Geotextile Stabilization Fabric:

High-Strength Support for Demanding Applications

The 315 woven geotextile stabilization fabric is engineered to provide exceptional tensile strength and durability for ground stabilization, drainage, and support in heavy-duty applications. With a grab tensile strength of 315 lbs, this high-strength woven geotextile is ideal for use under roads, railways, driveways, and other paved areas, offering reliable support and aggregate separation.

By incorporating the 315 woven geotextile into your construction projects, you can enhance the structural integrity of the pavement, prevent road failures, and extend the lifespan of the infrastructure. Its robust design ensures long-term performance, making it a cost-effective solution for challenging soil stabilization needs.

Call us now! 1-863-261-8388
or Contact us for additional information.

High Strength Woven Geotextile Fabric

High-strength woven geotextile fabrics are manufactured from durable, high-performance polypropylene fibers. These materials are engineered for load-bearing applications where soil stabilization, aggregate separation, and drainage performance are critical. Woven construction enhances tensile strength while maintaining structural integrity under heavy pressure.


Specifications

Property Test Method Minimum Avg. Roll Value (US)
Weight (typical) ASTM D5261 6 oz/yd² (203 g/m²)
Grab Tensile ASTM D4632 315 lbs (1.40 kN)
Grab Elongation ASTM D4632 15%
Trapezoid Tear Strength ASTM D4533 100 lbs (0.444 kN)
CBR Puncture Resistance ASTM D6241 120 lbs (.533 kN)
Permittivity* ASTM D4491 0.5 sec-1
Water Flow* ASTM D4491 4 gpm/ft² (163 l/min/m²)
A.O.S.* ASTM D4751 40 U.S. Sieve (.425 mm)
UV Resistance ASTM D4355 70 %/500 hrs

*Our high-strength woven geotextile products meet or exceed the specifications outlined above. The 315 woven stabilization fabric is available by the roll in standard sizes of 12.5' x 360' or 17.5' x 258'. For added flexibility, rolls can be purchased individually, by the pallet, or in truckload quantities to meet project demands at any scale.


Woven High Strength Geotextile Applications

The 315 woven geotextile stabilization fabric is engineered for exceptional tensile strength and structural reinforcement, making it an ideal solution for heavy-load environments. When compared to nonwoven alternatives, this woven fabric offers superior durability and long-term stability for demanding applications such as pavement reinforcement and riprap underlayment.


Common Use Cases:

  • Road construction, underlayment, and repair
  • Railroad base support and stabilization
  • Sports field construction and subsurface support
  • Erosion control for slopes, embankments, and channels
  • Embankment reinforcement and soil retention
  • Soil restoration and regrading projects
  • Athletic field repair and drainage management

Its ability to separate aggregates, reinforce soft soils, and prevent roadbed failure makes it a trusted material for infrastructure and environmental protection alike.


Choosing Between Woven and Nonwoven Geotextiles

In addition to high-strength woven products, we also offer a complete line of nonwoven geotextiles for filtration, drainage, and lighter stabilization needs.


Nonwoven Geotextile Options:

  • Lightweight (3–5 oz.): Ideal for landscaping, drainage wraps, and lightweight filtration.
  • Medium-weight (6–8 oz.): Used for moderate erosion control, slope protection, and subgrade stabilization.
  • Heavyweight (10–16 oz.): Suited for demanding filtration and support applications in high-flow areas.


More questions about woven geotextile stabilization fabric? Contact us at 1-863-261-8388 for more information or Contact Us through our webform.
