Environmental Dredging Geotubes

• Fabric: High-strength woven geotextile
• Length: Up to 200 ft
• Circumference: Up to 120 ft
• Effectively filters sediment, sludge, and waste
• Performs reliably in all weather conditions
• Simplifies removal and disposal of solids
• Enhances operational safety

Environmental Dredging Benefits

• Designed for large or small environmental dredging projects
• Available in large-capacity tube sizes
• Cost-effective, low-maintenance operation
• Durable and environmentally friendly

Environmental dredging is used in remediation of water in contaminated areas. Uncontrolled industry and domestic development result in the creation of contaminants in the sediment of waterways, lakes, rivers and harbors. These polluted sediments generate environmental risk because many of the pollutants stay in the sediments for a long time. Plants absorb contaminants and aquatic life ingest pollutants creating impurities in the animal and human food chain.

Environmental dredging disintegrates the sediment layer, raising the dredged material to the surface and making horizontal transportation of the contaminated sediment slurry possible. Performing the three stages of dredging in a controlled way with minimal disturbance and contamination of the surrounding area is the goal of environmental dredging.

1. Filling: The dredged in-coming contaminated sediment slurry is dosed with a chemical dewatering accelerant. The sediment slurry then enters the dewatering containers. The solids bind together, allowing the water to separate out.

2. Dewatering: The slurry water passes through the permeable skin of the geotube. Clear effluent water drains from the tube, leaving 99% of solids in the tube. Containers go through several filling and drawdown cycles before the dewatering is complete.

3. Consolidation: The effluent water drains to a location in the facility and is returned to its natural environment or is treated further to meet water quality standards. The contained solids are then transported to an offsite disposal facility or put to beneficial re-use.

Dredging Tube Specifications

*Custom sizing also available.

Needing to remove contaminated dredged sediment? Our environmental dredging bags or tubes provide a durable, cost-effective way to remove and dispose of contaminated sediment. Geotube dredging helps to keep contaminants out of city and county waterways by efficiently filtering and trapping dredging solids, so you can easily dispose of them.

Available in a variety of sizes for large-scale or smaller applications, our specially engineered geotextile dewatering bags effectively contain even hazardous materials, reducing volume and saving you thousands in disposal costs. These prefabricated containers are engineered with high-strength, quality-seaming techniques to give you an efficient and environmentally friendly solution for your dredging and dewatering applications. When your city and county needs to remove silt or sediment from the bottom of waterways, lakes, rivers and harbors, environmental dredging bags or tubes are an economical, effective tool.
